1,038 Pages Dedicated to Mastering Roof Penetrations

Pipe penetrations are among the most challenging details in standing seam roofing. FalzBook 1 breaks them down method by method, showing how experienced craftsmen form, connect, and weatherproof complex penetrations using traditional double-lock techniques.

• Massive 1,038-page technical reference
• Dedicated specifically to pipes, penetrations, and roof abutments
• Focuses on double-lock standing seam roofing techniques
• Suitable for both experienced sheet-metal craftsmen and developing roofers
• English / Russian
• 2024 edition

What’s Covered

Chapter 1 – Standing Double Seams: Straight Connections
Forming abutment components using standing double seams with straight seam placement.

Chapter 2 – Standing Double Seams: Diagonal Connections
Forming abutment components using standing double seams with diagonal seam placement.

Chapter 3 – Crickets & Water Diversion
Forming a cricket behind a pipe or penetration to properly divert water.

Chapter 4 – Lying Double Seams: Finnish & Swedish Methods
Forming abutment connections using lying double seams, including traditional Finnish and Swedish techniques.

Chapter 5 – Corner Double Seams
Forming pipe and penetration details using corner double-seam connections.

Chapter 6 – Combining Corner & Double-Seam Techniques
Using multiple seaming methods together to form complex pipe abutments.

Chapter 7 – Round Pipe Penetrations
Step-by-step methods for forming sheet metal abutments around round pipes.

Chapter 8 – Connecting Penetrations to Roof Panels
Integrating completed pipe and penetration details into the surrounding roofing system.

Chapter 9 – Origami Forming Methods
Creating complex abutment components by folding and forming the sheet metal from a single workpiece.
