DECOILERS SHIP VIA LTL, COMMERCIAL LOCATION ONLY, NO RESIDENTIAL DELIVERIES. EXPECT 1-2 WEEK LEAD TIME. We can quote to the nearest pickup point if you do not have a commercial location.

• Primarily used for uncoiling bulk coils in small sheets
• Six prong core
• Single locking spider system
• Friction brake
• Core expands from 15″ to 21″
• Instructions on setting up decoiler
• Casters can be purchased from McMaster-Carr – ESE Decoiler Caster Kit

• Specifications – Capacities:
  Max coil width: 24″
  Max outside diameter: 38″
  Core inside diameter: 15′ to 21″
  Max coil weight: 3,000 lbs
• Dimensions:
  Length: 36″
  Width: 35.5″
  Height (top of frame): 27″
  Height (top of core): 30″
  Height (top of core expanded): 32.5″
  Weight: 140 lbs
  Weight (core only): 66 lbs

Note:

*Decoiler returns will incur a 25% restocking fee – choose your model/size carefully

*Cannot ship internationally. Orders placed internationally will be voided
